WORX-DUTY 1GBWX73 GRAPPLE BUCKET

$2,895.00

Product Enquiry

Description

This Worx Duty Grapple Bucket is a heavy duty attachment designed for skid steer loaders and compact track loaders up to 100 horsepower. This attachment enables you to move hard-to-handle materials, brush and other awkward debris quickly and easily. Grapple has up to 44″ of fully usable opening

SAFETY FEATURES

  • Grapple opening of 44″ fully usable
  • Standard 5/8″ x 6″ bolt-on reversible cutting edge
  • Maximum clamping force of 3,600 lbs @ 3,000 psi
  • A pair of 3/16″ load transfer plates eliminates flex between the moldboard and hinge frame
  • Radius moldboard for strength and easy unloading
  • 1/2″ lid tines on 1-1/4″ pivot pins with robust broken-out lid decks for strength
  • Covered hoses for full protection in harsh environments
  • Includes hydraulic hoses and flat-faced couplers

SPECIFICATIONS

  • Model: 1GBWX73
  • Horsepower Recommended: Up To 100 Hp
  • Width – Overall: 73″
  • Width – Working: 73″
  • Maximum Opening: 44″
  • Cutting Edge: 5/8″ X 6″ Bolt-On / Reversible / Replaceable
  • Hydraulic Cylinder(s): Two (2) Hydraulic Cylinders, Included; 3,600 Lbs. @ 3,000 Psi
WorX-Duty Grapple Bucket 1GBWX73
