Our best-selling plate just got better! The new MVC88 now features a single cast baseplate and eccentric housing to enhance plate durability, serviceability, and performance. An hour/tachometer to help measure runtime and engine rpm is now a standard feature. The plate is even easier to transport with the new wheel kit design. All this combined with an advanced anti-vibration handle makes the MVC88 the newest and most technically advanced plate compactor on the market.

  • Reliable engine with Honda GX160 offering easy start-up and low oil shutdown for durability.
  • Cyclonic pre-cleaner captures most airborne contaminants for engine protection and extended service life.
  • Single cast baseplate and eccentric housing lowers center of gravity and increases travel speed by 12% for greater productivity.
  • Hour/tachometer measures runtime and engine rpm.
  • Tubular steel roll bar protects engine components and provides central lifting point.
  • Sealed belt cover keeps dirt and rocks out extending belt life.
  • Open base plate design makes for easier removal of dirt and rock build-up.
  • Cog-tooth belt drive enables longer life compared to conventional V-belts.
  • Optional urethane plate attachment for use on paving stones and brick pavers (UPA88T).
  • Optional transport wheel kit WHL88T for serial number T2A9197 and below.  WHL88TC for serial number T2A9198 and above.
  • Centrifugal Force: 3372 lbf 15 kN
  • Exciter Speed: 6000 VPM
  • Plate Size: 19.7 x 20.7 in
  • Max Forward Speed Per Min.: 82 ft
  • Fuel Consumption Per Hour: 0.31 gal
  • Overall Length: 41.75 in
  • Overall Width: 19.75 in
  • Overall Height: 37 in
  • Shipping Dimensions: 38 x 22 x 29 in
  • Operating Weight: 207 lb
  • Shipping Weight: 225 lb
PDF Version Multiquip MVC88VTH Specifications
PDF Version Multiquip MVC88VTH Operators Manual
