2016 Wacker Neuson G50 Generator #5044 - Fully Serviced 50KVA 38KW Generator Ready to Work | 9082 Hours

The G50 mobile generator offers the perfect power solution where single and three-phase power is needed for construction commercial, industrial and special event applications. The sound-attenuated generator provides quiet operation and the large fuel tank offers long run times, making it a flexible and reliable choice. A digital controller monitors and protects the generator and engine while providing continuous operating data on an easy-to-read LCD display.

  • Ideally suited for construction sites where durability, reliability and flexibility are required to supply continuous power for applications such as lighting, cranes, concrete mixers and conveyor belts.
  • Brushless, oversized alternators with separate excitation winding and AVR (Automatic Voltage Regulation) provide superior motor starting and enhanced ability to run non-linear loads.
  • Single switch start and simple, uncluttered control panel provide unmatched ease of use.
  • Automatic remote start capability standard which is ideal for temporary standby applications.
  • Factory-installed customized options are available. These include, but are not limited to, a fluid containment system, cold weather options, a camlock panel, etc. Also available are optional trailers that are fully equipped and highway ready.
  • L x W x H Operating (Skid): 96.25 x 38 x 53in
  • Weight Dry (Skid): 3,178 lb
  • Weight Operating (Skid): 3,783 lb
  • Weight Operating (Trailer): 4,663lb
  • Engine / Motor: Liquid-Cooled, 4 Cylinders
  • Engine / Motor manufacturer: John Deere
  • Emissions Certified: Tier 4i
  • Displacement in³: 275
  • Operating performance SAE J1995, ISO 8528-1 hp: 74
  • at rpm: 1,800
  • Coolant Capacity US qt: 20
  • Engine oil Capacity US qt: 15.9
  • Fuel type: Diesel
  • Fuel consumption (Prime Load) US gal/h: 3.4
  • Tank capacity -Fuel US gal: 84
  • Quantity (Battery): 1
  • Battery V: 12
  • Generator model: Mecc Alte, Brushless w/AVR
  • Voltage control No Load to Full Load +/- %: 1
  • Voltage control Steady State +/- %: 0.2
  • Generator insulation (class): H
  • Frequency (Generator Speed) Hz: 60
  • Runtime at 100% Prime Load h: 21.6
  • Runtime at 75% Prime Load h: 27.2
  • Runtime at 50% Prime Load h: 38.4
  • Runtime at 25% Prime Load h: 64.5
