26′ SCISSOR WIDE EL LIFT

Manufacturer: GENIE
Model: GS-2646
4 Hour: $173
Daily: $173
Product Enquiry

Description

Ideal for maneuvering in tight spaces, Genie® slab scissor lifts are excellent for indoor and outdoor construction, maintenance and installation applications with firm, level surfaces.

PRODUCTIVITY

  • Folding rails with full height swing gate
  • Dual front wheel drive
  • Universal 20 amp smart charger
  • Rear recessed charger receptacle
  • SmartLink™ – proportional lift and drive
  • Platform control with battery charge
    indicator and diagnostic display
  • On-board diagnostic system
  • AC power to platform
  • Lanyard attachment points
  • Manual platform lowering valve
  • Emergency stop at both platform and ground controls
  • Rear wheel multiple disc brakes
  • Front wheel hydraulic dynamic braking
  • Brake release
  • Swing-out component trays
  • Solid non-marking tires
  • Pothole guards
  • Tilt level sensor with audible alarm
  • Descent alarm
  • Electronic horn
  • Hour meter

MEASUREMENTS GS-2046

  • Working Height: 26 ft (8.10 m)
  • Lift Capacity: Up to 1,200 lbs (545 kg)
  • Platform Length Ouside: 7ft 5 in
  • Platform length extended: 10ft 5 in
  • Slide-out platform extension deck: 3ft (0.91m)
  • Platform width – outside: 3ft 9.3m
  • Toeboard height: 6in (0.15m)
  • Width: 3ft 10in
  • Wheelbase: 6ft 1in
  • Length stowed: 7ft 11in (2.41m)
  • Lengh extended: 10ft 10.5in (3.31m)
  • Ground clearance – center: 3.76in (95mm)
  • Ground clearance – with pothole guards deployed: 0.75in (0.019m)
  • Steel Platform: 89 x 45.3 in (2.26 x 1.15 m)
  • Extension Deck: 36 in (.91 m)

POWER

  • 24 V DC (four 6 V 225 Ah batteries)
  • Hydraulic System Capacity: 3.75gal 14.2L
Genie GS-2646 Scissor Lift

Genie GS-2646 Scissor Lift

PDF Version Genie GS-2646 Specifications
